Column Diameter 457 mm
Maximum Lifting Capacity 11 100 daN
Maximum Static Capacity 17 800 daN
Maximum travel 12.2 m
Maximum Speed 0.203 m/s
Closed height for travel of
1.2 m 393 mm
3 m 486 mm
6 m 644 mm
8.25 m 771 mm
12 m 962 mm
Lift Travel per Revolution (pitch) 105.1 mm
Drive Double Single Chain
Main Sprocket & Chain
or Main Gear Chain ANSI #80 80 teeth
Total System Lifting
Efficiency, EL 80 %
Column Material (bands) Stainless Steel 301
