Column Diameter 229 mm
Maximum Lifting Capacity 4 450 daN
Maximum Static Capacity 10 000 daN
Maximum travel 6.1 m
Maximum Speed 0.101 m/s
Closed height for travel of
1.2 m 259 mm
3 m 377 mm
6 m 577 mm
Lift Travel per Revolution (pitch) 52.9 mm
Drive Double Single Chain
Main Sprocket & Chain
or Main Gear Chain ANSI #60 54 teeth
Total System Lifting
Efficiency, EL 70 %
Column Material (bands) Stainless Steel 301
