Column Diameter 229 mm
Maximum Lifting Capacity 4 450 daN
Maximum Static Capacity 10 000 daN
Maximum travel 6.1 m
Maximum Speed 0.101 m/s
Closed height for travel of
1.2 m 273 mm
3 m 391 mm
6 m 591 mm
Lift Travel per Revolution (pitch) 52.9 mm
Drive Integrated Reducer with 2 Output Shafts
Total Ratios
(includes worm ratios), Rt 50.3, 25.15, 16.77, 12.64
Worm Gear Ratios, R 32.5, 16.25, 10.83, 8.17
Total System Lifting
Efficiency, EL up to 58 %
Column Material (bands) Stainless Steel 301
