Column Diameter 75 mm
Maximum Lifting Capacity 200 daN
Maximum Static Capacity 500 daN
Maximum travel 1.6 m
Maximum Speed 0.01 m/s
Closed height for travel of
1.2 m 137 mm
Lift Travel per Revolution (pitch) 25.1 mm
Drive Chain
Main Sprocket & Chain
or Main Gear Chain ANSI #40 46 teeth
Total System Lifting
Efficiency, EL 30 %
Column Material (bands) Stainless Steel 301
